MV triple-auger

Name: MV triple-auger
Brand: KOBLiK GROUP
SKU: MV triple-auger

Triple-auger feed mixer wagons with vertical augers — for preparing and distributing feed mixes (hay, silage, compound feed, etc.) on farms.

Volume from 37 to 50 m³

Model

Payload

from 11 to 13 t

Advantages

Minimal dimensions

Fit within the dimensions of tractors such as the MTZ-1523
Fast shredding of feed components

Thanks to three turbo-augers with 8 knives
Reduced spending on additional feeding equipment

Thanks to the large mass of feed prepared in one pass (from 11 t)
Fast unloading in the direction of auger movement

Thanks to the discharge chutes on the side of the mixer
Optimal control over feed-mix loading, mixing and unloading

Ensured by inspection windows
Increased wear resistance

Thanks to corrosion-resistant steel liners up to 1 m from the hopper bottom and augers with corrosion-resistant steel overlays (optional)

Request a quote

Description

Description
Technical data
Gallery

Professional feed mixer wagons with a vertical auger arrangement for the efficient preparation and uniform distribution of feed mixes on livestock farms. Suitable for working with various types of feed: hay, silage, compound feed, additives and liquids.

Data

Type	semi-trailer
Power frame version	frame
Weight, max (version with discharge chute), t	from 9.1 to 13.7
Payload, t	from 11 to 13
Volume, m³	from 25 to 34
Overall dimensions (version with discharge chute) (L/W/H), mm	from 8 730 to 10 270
	from 2 505 to 2 835
	from 2 984 to 3 420
Width over wheel side surfaces, mm	from 2 204 ± 5 to 2 545 ± 5
Bottom / wall thickness (mm)	20 / 8
Maximum side unloading height (maximum barrier height), mm	from 992 to 1 380
Loading height, min, mm	from 2 715 to 3 400
Ground clearance, min, mm	from 390 to 440
Transport speed loaded / unloaded, km/h	8 / 12
Working speed during feed distribution, km/h	5
Required tractor power, kW (hp)	from 110 (150) to 130 (177)
Tyre size (base version)	from 295 / 80 R22.5 to 385 / 55 R22.5
Number / type of augers	3 / from the tractor PTO
* 4 discharge windows
** reversible discharge conveyor / window rear left
Technical specifications are not binding and may vary depending on the configuration
